General Information
Products
| Manufacturer | Bosch |
| Product Type | Contact Housing |
| Number of positions | 60pcs |
| Code | C |
| Blade width | 0,6mm 1,5mm 2,8mm |
| Connection System | Wire-to-Device |
| Gender | Female |
| Sealed connection | Yes |
| Primary Locking (Terminal) | Clean body and lance |
| Colour | black |
| Body Material | PA 66 GF |
| Length | 56.5mm |
| Width | 44mm |
| Height | 36.4mm |
| Vibration Resistance | Car body |
| Temperature range, min. | -40° |
| Temperature range, max. | 105° |
| Terminal Sealing | Mat seal |
| Type of seal (connector) | radial seal |
| Type of seal (cable) | single wire seal for BDK 2.8 and mat seal for MQS 1.5 and BCB 0.6 |
| Type of locking mechanism (connector) | locking slide/lever |
| Secondary locking | Yes |
