General Information
Products
| Manufacturer | Bosch |
| Product Type | Connector Housing |
| Number of positions | 2pcs |
| Code | 1 |
| Blade width | 2.8mm |
| Connection System | Wire-to-Device |
| Gender | Female |
| Sealed connection | Yes |
| Primary Locking (Terminal) | Lance-locking |
| Colour | black |
| Body Material | PA 66 GF 30 |
| Length | 26.2mm |
| Width | 20.8mm |
| Height | 30.4mm |
| Minimum pitch | 5mm |
| Vibration Resistance | Engine / Transmission |
| Vibration strength | 25G |
| Temperature range, min. | -40° |
| Temperature range, max. | 150° |
| Terminal Sealing | Single wire seal |
| Type of seal (connector) | radial seal |
| Type of seal (cable) | single wire seal |
| Type of locking mechanism (connector) | plastic clip |
| Secondary locking | No |
| Additional features | with installed protective wall |
