General Information
Products
| Manufacturer | Bosch |
| Product Type | Clutch Connector |
| Number of positions | 3pcs |
| Code | 1 |
| Blade width | 2.8mm |
| Connection System | Wire-to-Wire |
| Gender | Male |
| Sealed connection | Yes |
| Primary Locking (Terminal) | Lance-locking |
| Colour | black |
| Body Material | PA 66 GF |
| Length | 24.1mm |
| Width | 17.2mm |
| Height | 33.5mm |
| Minimum pitch | 5mm |
| Vibration Resistance | Engine Compartment |
| Vibration strength | 20G |
| Temperature range, min. | -40° |
| Temperature range, max. | 150° |
| Terminal Sealing | Single wire seal |
| Type of seal (connector) | with axial seal at the cable harness connector |
| Type of seal (cable) | rubber cap |
| Type of locking mechanism (connector) | plastic or metal holder |
| Secondary locking | No |
